Project Description

Three edge carving bits

Code:1024

Material:integral tungsten steel

Coating: No Coating

Shank diameter: 3.175-6mm

Overall length:33-50mm

End type:Woodworking

Main features

*Tungsten steel material, sharp and durable, the cutter body is made of hard tungsten steel material by fine grinding, high hardness, high wear resistance

* Three-blade design, sharp carving, three-blade design of high strength carving sharper, smooth and wear-resistant

* Adopt advanced high temperature cold treatment technology, the cutter tip is more strong and sharp

* High concentricity, not easy to break the cutter, solid structure, excellent physical properties, longer tool life

*Universal round handle, chamfering design, fastening does not slip, higher working efficiency

Application

*Apply to

Mahogany, solid wood, acrylic, PVC, density board, double color board and other materials

*Capable of

All kinds of CNC engraving equipment

SHKANGLECDEOVLOrder No.
3.175150.1331024T01A15
3.175200.1331024T01A20
3.175300.1331024T01A30
3.175450.1331024T01A45
3.175600.1331024T01A60
3.175900.1331024T01A90
4300.1401024T01A30M4
4450.1401024T01A45M4
4600.1401024T01A60M4
4900.1401024T01A90M4
6300.1501024T01A30M6
6450.1501024T01A45M6
6600.1501024T01A60M6
6900.1501024T01A90M6
